Ideal Heat Pump - Pre-Plumbed Cylinders

Ideal Heat Pump – Pre-Plumbed Cylinders

Heat Pump cylinders

Hot water cylinders from the UK’s leading manufacturer of central heating systems. Complete your install in style with Ideal’s dependable unvented cylinders, complete with a 25 year warranty and available in sizes up to 400 litres. Made from stainless steel and manufactured to the highest standards, their range of hot water cylinders are designed to perfectly complement the Ideal Logic Air & HP290 Air Source Heat Pumps. (Ensure that you select the correct model of Cylinder to match either the R32 Logic Air or the R290 HP290)

SCROLL DOWN FOR FURTHER INFORMATION

For price, please select a model below

Models

Clear

SKU: N/A Category: Cylinders Brand: Ideal

Product Information
Additional information

Description

SINGLE HEATING ZONE		DHW CYL PP150 CBOX 1Z SL	DHW CYL PP180 CBOX 1Z SL	DHW CYL PP150 CBOX 1Z	DHW CYL PP180 CBOX 1Z
LOGIC AIR R32 Cylinder Code		LOGIC-32-PP150-1Z-SL	LOGIC-32-PP180-1Z-SL	LOGIC-32-PP150-1Z	LOGIC-32-PP180-1Z
HP290 Cylinder Code		240127	240128	240122	240123
Energy Efficiency Class	Erp	B	C	B	C
Heat Loss	Watts/h	50	58	44	49
Capacity	Litres	145	169	148	170
Weighty Empty	kg	46	53	44	49
Weight Full	kg	192	222	192	219
Overall Width	mm	581	581	636	636
Overall Height	mm	1598	1870	1196	1384
Overall Depth	mm	606	606	683	683
Coil Area	m²	1.8	3.0	1.6	2.5
Reheat Time 10°C to 50°C	min	22.26	21.81	22.56	22.56
Immersion Heater	kW	3	3	3	3

TWO HEATING ZONES		DHW CYL PP210 CBOX LL 2Z SL	DHW CYL PP210 CBOX LL 2Z SL	DHW CYL PP250 CBOX LL 2Z	DHW CYL PP300 CBOX LL 2Z
LOGIC AIR R32 Cylinder Code		LOGIC-32-PP210-2Z-SL	LOGIC-32-PP210-2Z-SL	LOGIC-32-PP250-2Z	LOGIC-32-PP300-2Z
HP290 Cylinder Code		240129	240124	240125	240126
Energy Efficiency Class	Erp	C	B	C	C
Heat Loss	Watts/h	65	55	63	72
Capacity	Litres	188	199	237	279
Weighty Empty	kg	60.6	64	69.8	73.4
Weight Full	kg	248.9	262.8	307	352.4
Overall Width	mm	647	704	704	704
Overall Height	mm	2042	1572	1822	2068
Overall Depth	mm	620	686	686	686
Coil Area	m²	2.5	2.5	3	3
Reheat Time 10°C to 50°C	min	23.68	30.6	27.34	35.05
Immersion Heater	kW	3	3	3	3

ONE HEATING ZONE c/w BUFFER		DHW CYL PP180 CBOX BUFF 1Z	DHW CYL PP210 CBOX BUFF 1Z	DHW CYL PP250 CBOX BUFF 1Z	DHW CYL PP300 CBOX BUFF 1Z
LOGIC AIR R32 Cylinder Code		236206	236208	236210	236212
HP290 Cylinder Code		240130	240132	240134	240136
Energy Efficiency Class	Erp	B	B	B	B
Heat Loss	Watts/h	49	55	62	68
Capacity	Litres	171	199	239	287
Weighty Empty	kg	64.6	68.6	77	87
Weight Full	kg	305.6	337.4	379	437.5
Overall Width	mm	644	644	705	705
Overall Height	mm	1907	2095	1908	2128
Overall Depth	mm	702	702	780	780
Coil Area	m²	2.5	2.5	2.5	3
Reheat Time 10°C to 50°C	min	22.17	32.71	26.56	44.09
Immersion Heater	kW	3	3	3	3

TWO HEATING ZONE c/w BUFFER		DHW CYL PP180 CBOX BUFF 2Z	DHW CYL PP210 CBOX BUFF 2Z	DHW CYL PP250 CBOX BUFF 2Z	DHW CYL PP300 CBOX BUFF 2Z
LOGIC AIR R32 Cylinder Code		236207	236209	236211	236213
HP290 Cylinder Code		240131	240133	240135	240137
Energy Efficiency Class	Erp	B	B	B	B
Heat Loss	Watts/h	49	55	62	68
Capacity	Litres	171	199	239	287
Weighty Empty	kg	68	71.8	80	90.2
Weight Full	kg	309	340.6	382	439.7
Overall Width	mm	644	644	705	705
Overall Height	mm	1907	2095	1908	2128
Overall Depth	mm	702	702	780	780
Coil Area	m²	2.5	2.5	2.5	3
Reheat Time 10°C to 50°C	min	22.17	32.71	26.56	44.09
Immersion Heater	kW	3	3	3	3

Additional information

Models	LOGIC-32-PP150-1Z-SL, LOGIC-32-PP180-1Z-SL, LOGIC-32-PP150-1Z, LOGIC-32-PP180-1Z, 240127, 240128, 240122, 240123, LOGIC-32-PP210-2Z-SL, LOGIC-32-PP210-2Z, LOGIC-32-PP250-2Z, LOGIC-32-PP300-2Z, 240129, 240124, 240125, 240126, 236206, 236208, 236210, 236212, 240130, 240132, 240134, 240136, 236207, 236209, 236211, 236213, 240131, 240133, 240135, 240137
