Description
| Outdoor Unit Model | RAS 2WHVNP | RAS 2.5 WHVNP | RAS 3WHVNP | RAS 4WH(V)NP | RAS 5WH(V)NP | RAS 6WH(V)NP | RAS 8WHVNP | RAS 10WHVNP | |
| Refrigerant | R410A | ||||||||
| Minimum Piping Length | m | 5.0 | |||||||
| Maximum Chargeless Piping Length | m | 15.0 | |||||||
| Piping Diameter (liquid/gas) | Inch | 3/8 / 5/8" | 1/4" / 1/2" | 3/8" / 1 1/8" | 1/2" / 1 1/8" | ||||
| Maximum Piping Length | m | 50.0 | 75.0 | ||||||
| Additional Refrigerant Charge | g (per metre) | 30.0 | 40.0 | 60.0 | |||||
| Power Supply | 230V/1Ph/50Hz | 230V/1Ph/50Hz + 400V/3PH/50Hz | 400V/3Ph/50Hz | ||||||
| Circuit Breaker Size (Single/Three Phase) | A | 20 | 32/16 | 24 | |||||
| Maximum Operating Current | A | 13.8 | 15.8 | 17.8 | 30.5/14 | 30.5/16 | 24.0 | ||
| Sound Power Level @ 7/35* | dB(A) | 59.0 | 60.0 | 61.0 | 63.0 | 64.0 | 65.0 | 71.0 | 72.0 |
| Dimensions (H x W x D) | mm | 600 x 792 x 300 | 1380 x 950 x 370 | ||||||
| Gross Weight | Kg | 46.0 | 49.0 | 116.0 | 137.0 | 139.0 | |||
| Compressor Type | mm | Scroll DC Inverter Driven | |||||||
| * Sound power level in accordance to the standard EN 12102 at conditions specified in EN 14511 performance test | |||||||||
Features and Benefits:
- Domestic hot water as well as heating – ideal boiler replacement technology
- Two heating circuits
- Screed drying function ideal for new builds
- Weather compensation control
- Generate water up to 60°C
- DHW legionella protection program
- Capable of producing domestic hot water when combined with optional hot water tank
- One of the best COP’s on the market up to 5.25
- Eligible for domestic and non-domestic RHI
- ErP energy efficiency class of up to A+++
- Remote Controller PC-ARFHE (Includes; weekly timer, holiday mode, smart function and a favourite button)
- Wireless Remote Thermostat ATW-RTU-05 (Control remotely via smartphone app)
- Optional cooling accessory available
- Optional domestic hot water tank and buffer tanks
- Available from 4.3 to 24 kW, single and three phase models available
Advanced Technical Data
| Indoor Unit Model | RWM 2.0NE | RWM 2.5NE | RWM 3.0NE | RWM 4.0NE | RWM 5.0NE | RWM 6.0NE | RWM 8.0NE | RWM 10.0NE | |
| Outdoor Unit Model | RAS 2WHVNP | RAS 2.5WHVNP | RAS 3WHVNP | RAS 4WH(V)NP | RAS 5WH(V)NP | RAS 6WH(V)NP | RAS 8WH(V)NP | RAS 10WH(V)NP | |
| Nominal Capacity (max) Water 30/35°C, Ambient 7db/6wb°C | KW | 4.30 (7.00) | 6.00 (9.00) | 7.50 (11.00) | 11.0 (15.20) | 14.0 (16.70) | 16.00 (17.80) | 20.00 (25.50) | 24.0 (32.00) |
| COP | 5.25 | 4.8 | 4.55 | 5.00 | 4.71 | 4.57 | 4.57 | 4.30 | |
| Nominal Capacity (max) Water 40/45°C, Ambient 7db/6wb°C | KW | 4.30 (6.20) | 6.00 (9.00) | 7.50 (10.00) | 11.0 (14.10) | 14.0 (15.70) | 16.00 (17.30) | 20.00 (25.00) | 24.0 (32.00) |
| COP | 3.9 | 3.59 | £3.50 | 3.98 | 3.61 | 3.40 | 3.40 | 3.30 | |
| Nominal Capacity (max) Water 47/55°C, Ambient 7db/6wb°C | KW | 4.30 (6.00) | 6.00 (8.00) | 7.50 (9.20) | 11.0 (13.5) | 14.0 (15.20) | 16.00 (17.00) | 20.00 (24.00) | 24.0 (32.00) |
| COP | 3.00 | 2.89 | 2.57 | 3.00 | 2.80 | 2.50 | 2.72 | 2.65 | |
| Nominal Capacity (max) Water 30/35°C, Ambient 2db/1wb°C | KW | 3.50 (5.50) | 4.50 (7.00) | 5.50 (8.90) | 9.50 (12.80) | 10.50 (13.90) | 11.10 (15.00) | 12.30 (20.00) | 13.00 (20.70) |
| COP | 4.10 | 3.65 | 3.53 | 3.61 | 3.55 | 3.41 | 3.51 | 3.41 | |
| Nominal Capacity (max) Water 30/35°C, Ambient -7db/-8wb°C | KW | 4.30 (4.70) | 5.30 (5.70) | 5.80 (6.70) | 9.70 (10.60) | 11.50 (12.00) | 12.00 (13.00) | 14.20 (17.90) | 16.50 (21.00) |
| COP | 2.85 | 3.65 | 2.57 | 2.74 | 2.65 | 2.57 | 2.57 | 2.57 | |
| Nominal Capacity (max) Water 40/45°C, Ambient -7db/-8wb°C | KW | 4.30 (4.60) | 5.00 (5.50) | 6.00 (6.40) | 10.0 (10.00) | 11.00 (11.60) | 11.50 (12.50) | 15.00 (16.60) | 16.50 (18.50) |
| COP | 2.45 | 2.25 | 2.25 | 2.45 | 2.25 | 2.15 | 2.08 | 1.74 | |
| Nominal Capacity (max) Water 47/55°C, Ambient -7db/-8wb°C | KW | 4.00 (4.20) | 4.60 (5.00) | 5.00 (5.50) | 8.70 (9.70) | 9.70 (11.20) | 10.50 (12.00) | 12.50 (14.50) | 15.50 (17.30 |
| COP | 1.93 | 1.82 | 1.6 | 1.78 | 1.85 | 1.75 | 1.7 | 1.5 | |
| Water Flow Rate min/max | m3/hr | 0.5/1.9 | 0.6/2.0 | 0.6/2.1 | 1.0/2.9 | 1.1/3.0 | 1.2/3.0 | 2.0/4.5 | 2.2/4.6 |
| Minimum Water Volume (defrost) | L | 28.0 | 28.0 | 28.0 | 38.0 | 46.0 | 55.0 | 76.0 | 79.0 |
| Water Connections | Inch | 1" Female | 1 1/4" Female | ||||||
| Expansion Vessel Size | L | 6.0 | 10.0 | ||||||
| Pump Type | Yonos PARA RS 15/7.0 | Ronos PARA RS 15/7.5 | UPML GEO 25-105 | ||||||
| Water Temperature Range | °C | 20 - 55 | 20 - 60 | ||||||
| Piping Diameter (liquid/gas) | Inch | 1/4" / 5/8" | 3/8" / 5/8" | 3/8" / 1.18" | 1/2" / 1 1/8" | ||||
| Power Supply | 230V/1Ph/50Hz | 230V/1Ph/50Hz + 400V/3PH/50Hz | 400V/3Ph/50HZ | ||||||
| Circiut Breaker Size (with DHW tank heater) | A | 20.0 | |||||||
| Maximum Operating Current (with DHW tank heater) | A | 15.3 | 15.4 | ||||||
| Sound Power Level | dB(A) | 37.0 | 39.0 | 47.0 | |||||
| Dimensions (H x W x D) Including Connections | mm | 782 x 450 x 275 | 960 x 520 x 360 | 960 x 670 x 360 | |||||
| Gross Weight | Kg | 60.0 | 61.0 | 71.0 | 90.0 | 93.0 | |||
